Bently Nevada 330103-00-03-10-01-05 8 mm Proximity Probe
An M10 × 1 probe with a 30 mm case, 1.0 m cable, connector protector and multiple-approval option.
Product Identification
330103-00-03-10-01-05 is a metric 3300 XL 8 mm proximity probe with an M10 × 1 thread and no armor. Its code defines zero unthreaded length, a 30 mm overall case and a 1.0 m total probe length.
The standard cable terminates in a miniature ClickLoc connector with protector, and suffix 05 selects the multi-approval option. The probe must be matched to the extension cable and 3300 XL Proximitor as a complete calibrated system.
Engineering Data
| Manufacturer | Bently Nevada, a Baker Hughes business |
|---|---|
| Model | 330103-00-03-10-01-05 |
| Product Family | 3300 XL 8 mm |
| Probe Thread | M10 × 1 |
| Armor | Without armor |
| Unthreaded Length | 0 mm |
| Overall Case Length | 30 mm |
| Probe Total Length | 1.0 m |
| Connector / Cable | ClickLoc with connector protector, standard cable |
| Approval Option | CSA / ATEX / IECEx |
Functions
- Measures static position and dynamic vibration within a complete eddy-current transducer system.
- Uses a short metric threaded case for compact mounting arrangements.
- Includes a connector protector for the ClickLoc connection.
- Supports approved installations when the full transducer loop and wiring comply.
Applications
- Fluid-film bearing vibration measurement
- Axial position monitoring
- Keyphasor and speed-reference service
Lifecycle
- Protect the probe tip, M10 threads and ClickLoc connector during storage.
- Keep probe, extension-cable and Proximitor identities in the same asset record.
- Retain hazardous-area documentation with the complete measurement loop.
FAQ
What mechanical configuration does 330103-00-03-10-01-05 use?
It uses an M10 × 1 unarmored probe case with zero unthreaded length and a 30 mm overall case.
Does 330103-00-03-10-01-05 include a connector protector?
Yes. Code 01 selects the standard cable with a ClickLoc connector protector.
Can 330103-00-03-10-01-05 use any extension-cable length?
No. Probe and extension-cable lengths must equal the selected 3300 XL Proximitor system length.
Is 330103-00-03-10-01-05 interchangeable with an imperial 330101 probe?
Do not assume so; thread, case geometry and installation hardware differ even though both belong to the 8 mm family.
What approval checks apply to 330103-00-03-10-01-05?
Review the probe, cable, Proximitor, barriers or isolators and installation drawing as one approved loop.
What should be recorded before replacing 330103-00-03-10-01-05?
Capture insertion depth, gap voltage, extension cable, Proximitor part, monitor channel and the complete area-classification record.
