Bently Nevada 330104-00-04-10-02-05 3300 XL Probe
An armored metric M10x1 3300 XL 8 mm probe with 40 mm case, 1.0 m lead and multiple approvals.
Overview
330104-00-04-10-02-05 is the armored M10x1 version of the Bently Nevada 3300 XL 8 mm proximity probe. Its code specifies zero unthreaded length, a 40 mm case, 1.0 m total lead, standard ClickLoc cable and approval option 05.
The armored body, matching extension cable and Proximitor Sensor form one electrical system. Confirm the installed system length and approval requirement rather than mixing fields from a nearby 330103 or 330104 code.
Specs
| Manufacturer | Bently Nevada, a Baker Hughes business |
|---|---|
| Model | 330104-00-04-10-02-05 |
| Product Family | 3300 XL 8 mm proximity transducer system |
| Thread | Metric M10x1 |
| Armor | Armored probe |
| Unthreaded Length | 0 mm |
| Case Length | 40 mm |
| Total Length | 1.0 m |
| Connector / Cable | 02: ClickLoc connector, standard cable |
| Approval Field | 05: CSA/ATEX/IECEx multiple approvals; verify delivered marking |
| System Scale Factor | 200 mV/mil nominal with matched system |
| System Linear Range | 80 mils (2.0 mm) with matched 8 mm system |
Features
- Provides mechanical protection for the probe lead in industrial installations.
- Uses a metric M10x1 threaded body with a short 40 mm case.
- Keeps the approval selection visible in the part number for controlled sourcing.
- Integrates with the matched 3300 XL extension and Proximitor components.
Applications
- General rotating-machine vibration and position monitoring.
- Armored cable routes in plant machinery and skids.
- Replacement of an existing 330104 metric probe with the same order fields.
Lifecycle
- Verify M10x1 engagement, insertion depth and target gap before installation.
- Check the approval marking on probe, extension and Proximitor as a complete chain.
- Protect ClickLoc connectors from contamination and sharp bend radius.
- Record system length and installed cable route for future replacement.
FAQ
How does 330104-00-04-10-02-05 differ from 330103-00-06-10-02-00?
330104-00-04-10-02-05 is armored, uses a 40 mm case and carries approval field 05; the 330103 code is unarmored and has different geometry and approval status.
What does the 05 suffix require for 330104-00-04-10-02-05?
Verify the actual CSA/ATEX/IECEx marking on the delivered probe and all other parts of the hazardous-area system.
Why is the 40 mm case important for 330104-00-04-10-02-05?
It controls fit and insertion geometry; the case length must agree with the installation drawing and target gap.
Which cable fields should be checked with 330104-00-04-10-02-05?
Confirm the 1.0 m probe lead, 02 standard ClickLoc option, extension length and Proximitor type as one system.
What should be sent for a 330104-00-04-10-02-05 quote?
Provide the old probe label, thread and case drawing, system length, target details and required approval.
