Extends the electrical connection between a compatible 3300 XL probe and Proximitor Sensor.
Product Overview
330130-075-01-00 is a Bently Nevada 3300 XL standard extension cable with a 7.5 metre length and protective armor.
The standard cable is 75 Ω triaxial cable with FEP insulation. Its published operating and storage temperature range is −52 to +177 °C and the minimum bend radius is 25.4 mm.
The probe length plus this extension-cable length must equal the system length specified for the Proximitor Sensor.
Performance
Maintains the standard 75 Ω triaxial cable construction within the calibrated measurement chain.
Adds flexible stainless-steel armor with an FEP outer jacket.
Provides the exact 7.5 metre length required by the selected system combination.
Technical Details
Manufacturer
Bently Nevada
Exact model
330130-075-01-00
Cable family
3300 XL standard extension cable
Cable length
7.5 m
Cable protection
Armor
Approval option
Not required
Cable construction
75 Ω triaxial with FEP insulation
Operating and storage temperature
−52 to +177 °C
Minimum bend radius
25.4 mm
Connector materials
Gold-plated brass and beryllium copper
System rule
Probe length plus extension length must match Proximitor system length
System Integration
About IndustryParts
https://www.industryparts.com/Cable length and transducer calibration remain one record
IndustryParts checks 330130-075-01-00 against the complete probe and Proximitor system before supply.
7.5 m length confirmed
Armored option retained
System combination reviewed
Applications
3300 XL proximity systems requiring a 7.5 metre standard extension cable.
Armored cable routes where the approved flexible protection is required.
Machine-monitoring installations within the standard published temperature range.
Exact replacement of the 330130-075-01-00 execution.
FAQ
Q01How is 330130-075-01-00 matched to a Proximitor Sensor?
Add the connected probe length to the 7.5 metre cable length and match the resulting total to the Proximitor system length.
Q02What cable construction is used by 330130-075-01-00?
It uses the 3300 XL standard 75 Ω triaxial cable with FEP insulation and the armored option.
Q03What routing limit matters for 330130-075-01-00?
Maintain at least the published 25.4 mm bend radius and avoid strain at either connector.
Q04Can 330130-075-01-00 replace an ETR extension cable?
Not in an extended-temperature application; the 330190 ETR family has a different insulation and temperature boundary.
Q05What should accompany a 330130-075-01-00 enquiry?
Provide the probe model and length, Proximitor Sensor model and system length, cable-route conditions, quantity and destination.
