Bently Nevada 330130-080-13-05 Sensor Probe Cable Extension

Bently Nevada 330130-080-13-05 Sensor Probe Cable Extension

Item NO.: 3232004
Inquiry

Warranty: 1 year


Condition : brand new in factory sealed box


Email: sales@mvme.cn


Chat online: +86 18030175807

Detail

  • Product NameBently Nevada 330130-080-13-05 Sensor Probe Cable Extension
  • Item NO.3232004
  • Weight1.0000 kg = 2.2046 lb = 35.2740 oz
  • CategoryTSI
  • BrandBently Nevada
  • Creation Time2025-06-12
  • 3300 XL 8 mm Armored FluidLoc Cable with Connector Protector
3300 XL 8 mm | 8.0 m armored FluidLoc construction

Bently Nevada 330130-080-13-05 Armored FluidLoc Extension Cable

An 8.0 m armored FluidLoc extension cable with connector protector and the CSA, ATEX and IECEx approval option.

BrandBently Nevada
Model330130-080-13-05
Product Type3300 XL 8 mm Armored FluidLoc Cable with Connector Protector
01

Product Profile

330130-080-13-05 is an 8.0 m (26.2 ft) 3300 XL extension cable. The 13 construction code specifies armored FluidLoc cable with a connector protector, and the final 05 code identifies the multiple-approval option.

FluidLoc construction is intended for defined applications where the cable environment requires that option. The complete system must still combine the probe lead and extension cable to match the Proximitor Sensor total length.

02

Technical Data

Manufacturer Bently Nevada, a Baker Hughes business
Model 330130-080-13-05
Series 3300 XL 8 mm
Cable Length 8.0 m (26.2 ft)
Cable Construction Armored FluidLoc cable with connector protector
Electrical Cable Family 75 Ω triaxial
Armor Material Flexible AISI 302 or 304 stainless steel with FEP outer jacket
Agency Approval Option CSA, ATEX and IECEx
Minimum Cable Bend Radius 25.4 mm (1.0 in)
Maximum Connector Torque 0.565 N·m (5 in·lbf)
System-Length Rule Probe lead plus 8.0 m cable must equal Proximitor total length
03

System Role

  • The 8.0 m cable extends the probe connection to the Proximitor Sensor without becoming a standalone measuring device.
  • FluidLoc and stainless-steel armor address the ordered cable-construction requirement.
  • The connector protector adds environmental protection at the factory-configured junction.
  • The 05 suffix carries the defined CSA, ATEX and IECEx approval selection.
04

Compatibility

  • A 1.0 m probe lead commonly combines with the 8.0 m cable for a 9.0 m Proximitor system; verify the actual codes.
  • Confirm that FluidLoc construction is suitable for the process and routing conditions before replacement.
  • Preserve the armored route without violating the 25.4 mm minimum bend radius.
  • Use only within a documented 3300 XL 8 mm transducer-system configuration.
05

Applications

  • Machinery-monitoring cable routes requiring FluidLoc construction and mechanical armor.
  • Shaft vibration and position loops with an 8.0 m extension segment.
  • Approved installations requiring the 05 certification option and connector protection.
  • Maintenance replacement where fluid exposure, routing and total system length have been confirmed.
06

FAQ

How long is 330130-080-13-05?

The 080 code specifies an 8.0 m (26.2 ft) extension cable.

What construction does 330130-080-13-05 use?

Option 13 specifies armored FluidLoc cable with a connector protector.

What approvals are attached to 330130-080-13-05?

The 05 suffix identifies CSA, ATEX and IECEx approvals.

Which probe length is commonly paired with 330130-080-13-05?

A 1.0 m probe lead commonly forms a 9.0 m system with the 8.0 m cable, subject to exact part-number verification.

Can 330130-080-13-05 be replaced by a standard unarmored cable?

Not without engineering review; cable construction, protection, routing and certification would change.

What should be checked when routing 330130-080-13-05?

Confirm FluidLoc suitability, protect the connector, maintain bend radius and preserve the correct total electrical length.
