Eaton TM-2-8241E Step Switch

Eaton TM-2-8241E Step Switch

Eaton TM-2-8241E Step Switch is a manually operated control switch designed for multi-position circuit selection in industrial electrical systems. Eaton TM-2-8241E Step Switch features a 4-position (0–3) configuration, 10 A rated current, 500 V AC rating, 45° switching angle, latching mechanism, and IP65 front protection, making it suitable for reliable operation in demanding environments.

Eaton TM-2-8241E Step Switch is widely used in industrial automation, machinery control panels, power distribution systems, and equipment control applications. Eaton TM-2-8241E Step Switch is ideal for industries such as manufacturing, energy, HVAC, and process control where manual switching between different operating modes is required.

☈ Product Information

Product Name: Eaton TM-2-8241E Step Switch

Product Model: TM-2-8241E

Product Parameters: Step Switch

Manufacturer: Eaton

Weight: 0.04 kg

Number of poles: 1

Max. rated operating voltage (Ue) at AC: 500 V

Rated continuous current (Iu): 10 A

Number of switching positions: 4

With zero position: Yes

With retreat in zero position: No

Device construction: Built-in device

Suitable for ground mounting: No

Suitable for front attachment: Yes

Suitable for distributor installation: No

Suitable for intermediate construction: No

Complete device in the housing: No

Execution of the actuating element: Clamping bolt

Front shield size: 30 × 30 mm

Degree of protection (IP), front side: IP65

Degree of protection (NEMA), front side: 12

Place of Shipment: Xiamen, China

Delivery Time: 1-3 days

Quantity: 100% New Original

Minimum Order Quantity: 1pc

Shipping Method: DHL\UPS\Fedex\EMS\Others
