Provides four analog voltage command channels in one VersaMax I/O position.
Technical Summary
IC200ALG322 is a VersaMax four-channel analog voltage output module. The manufacturer catalog identifies 12-bit conversion and a ±10 V output range.
The module belongs to the carrier-mounted VersaMax I/O platform. Carrier type, terminal arrangement, field wiring and configured ranges remain part of the installed assembly.
Exact catalog identity matters because adjacent IC200ALG output modules differ in channel count, signal type and resolution.
Specifications
| Manufacturer family | GE Fanuc VersaMax; supported in the Emerson legacy portfolio |
|---|---|
| Exact catalog number | IC200ALG322 |
| Product type | Analog voltage output module |
| Number of channels | 4 |
| Resolution | 12 bit |
| Documented output range | ±10 V |
| Platform | VersaMax modular I/O |
| Mounting architecture | VersaMax carrier and terminal assembly |
| Configuration boundary | Controller configuration, channel scaling and field wiring |
Features
Uses 12-bit conversion for the documented ±10 V output function.
Separates the removable electronic module from the VersaMax carrier and terminal wiring.
Uses an exact catalog number that distinguishes it from current-output and higher-channel-count variants.
Compatibility
- Confirm the installed VersaMax carrier, terminal style and controller configuration before ordering.
- Record each channel range, engineering-unit scaling, commanded device and shield or grounding arrangement.
- Verify the field device accepts a ±10 V command and that its common reference matches the approved wiring drawing.
- Do not replace IC200ALG322 with another IC200ALG number solely because the housing and connector appear similar.
Replacement
- Save the PLC configuration and trend or record the safe output state for every channel.
- Place the process in a safe condition, remove field power as required and label carrier and terminals.
- Install the exact module, restore configuration and verify zero, polarity and span with controlled commands.
- Confirm each final control element responds correctly before the loop is returned to automatic control.
FAQ
Q01
Can IC200ALG322 be selected from the VersaMax family name alone?
No. The full catalog number is needed because VersaMax analog modules differ in signal type, channel count and resolution.
Q02
What information should accompany an IC200ALG322 enquiry?
Provide the module and carrier labels, rack position, controller configuration, channel ranges, loop drawings and terminal photographs.
Q03
Can a current-output VersaMax module replace IC200ALG322 without changes?
No direct substitution should be assumed; voltage and current outputs require different module selection, configuration and field wiring.
Q04
How should stored IC200ALG322 modules be screened before use?
Inspect connector contacts and housing, verify the exact label and stage a bench check with the approved carrier and configuration.
Q05
What proves all four outputs are ready for service?
Command controlled values on each channel and verify polarity, zero, span, scaling, field-device response and safe-state behavior.
