Operates as the master for configured PROFIBUS-DP slave exchanges.
Key Information
IC693PBM200 is the PROFIBUS-DP Master module listed by Emerson for supported PACSystems RX3i and legacy Series 90-30 configurations.
The module manages the cyclic exchange with configured PROFIBUS-DP slaves. Its practical identity includes the rack slot, CPU firmware, baud and bus settings, slave addresses and imported device descriptions.
Public documentation confirms the master-module role; detailed project limits should be taken from the applicable GFK-2121 manual revision and the installed engineering project.
Functions
Keeps slave addresses and diagnostic data linked to the controller project.
Supports legacy installed bases where exact network configuration is critical.
Requires project and bus evidence rather than a visual-only module match.
Specifications
| Manufacturer | Emerson / legacy GE Fanuc |
|---|---|
| Exact model | IC693PBM200 |
| Platform | Series 90-30 / supported PACSystems RX3i configurations |
| Module function | PROFIBUS-DP Master |
| Network role | Controls configured PROFIBUS-DP slave devices |
| Engineering data | Slave addresses, baud rate, bus parameters and device descriptions |
| Host requirement | Confirm CPU firmware and rack support from the applicable system manual |
| Configuration reference | IC693PBM200 User Manual, GFK-2121 |
| Replacement boundary | Module, slot, bus connector, termination and complete network project |
Installation
- Back up the controller and PROFIBUS configuration, including every slave and device-description file.
- Record the module slot, bus address, cable shield, connector termination and active diagnostics.
- Confirm CPU firmware and engineering-software support before installing a replacement.
- Commission the network from a controlled state and verify each slave, data area and fault response.
Lifecycle
- Retain the bus drawing, GSD files and controller project with the spare record.
- Inspect connectors, shield bonding and end-of-segment termination during maintenance.
- Do not substitute a PROFIBUS slave module or a different master family for IC693PBM200.
- Archive network diagnostics before and after the exchange.
About IndustryParts
https://www.industryparts.com/The network project is part of the spare
IndustryParts handles IC693PBM200 with the CPU, rack, slave list and bus-termination evidence needed to restore the same PROFIBUS segment.
- Slave list retained
- Bus termination reviewed
- Project compatibility checked
Related Models
| 3277+3244 DN100+3730-1 | CPO-RS6 | SL-VP7PM |
| LP 050S-MF2-16-1B1-3S | 4PP015.E420-36 | 7kt0311 |
| RF57 DAS100L4/TF/IS | FW 91108 S91108 | G50BB124MVAR2C00 E84DGFCRENP |
| HE-67P3-0N00P | EP1008-0002 | Legrand 44523 |
| 03608 | 3RB2906-2JG1 | B9 YH5/3 |
| MPL-B33P-SK22AA | SBX-NCR | KT49 DRN90S4/TF |
| T91A61 5017-611 | Rexroth MSK101E-0450-NN-M1-BG3-NNN R911321194 | EC 6-133 P220 |
| CU230P-2BT 6SL3243-6BB30-1HA3 | 7D1439.7 | SK3105.190 |
| 12R 72405900 | 2CDG 110 064 R0011 | HKC50A10 |
| Puls SL10.100 | RA 0010 B 543 | KFD2-STC4-EX1-KFD2-STC4-EX1-KFD2 |
FAQ
Q01What should accompany an IC693PBM200 enquiry?
Provide the complete label, rack and CPU models, CPU firmware, slot, engineering-software release, PROFIBUS baud rate, slave list and bus drawing.
Q02Can IC693PBM200 be installed without the original project?
Physical installation alone is insufficient. The master requires the approved slave and data configuration; recover and validate the project before planned replacement.
Q03What bus hardware should be checked before blaming IC693PBM200?
Inspect segment power, cable, shields, connector seating, termination at both ends, duplicate addresses and the diagnostics of each affected slave.
Q04Can a newer PROFIBUS master automatically replace IC693PBM200?
Only with a manufacturer-supported migration covering CPU, rack, project conversion, data mapping, timing and all slave behavior.
Q05What proves IC693PBM200 is ready after replacement?
Confirm clean master diagnostics, every slave in data exchange, correct input/output mapping, stable bus statistics and the approved machine response.
