Honeywell 8C-TAIXA1 51307127-175 Analog Input Module

Honeywell 8C-TAIXA1 51307127-175 Analog Input Module

Item NO.: 3538656
Inquiry

Warranty: 1 year


Condition : brand new in factory sealed box


Email: sales@mvme.cn


Chat online: +86 18030175807

Detail

  • Product NameHoneywell 8C-TAIXA1 51307127-175 Analog Input Module
  • Item NO.3538656
  • Weight0.0000 kg = 0.0000 lb = 0.0000 oz
  • CategoryDCS
  • BrandHoneywell
  • Creation Time2026-02-09
  • Honeywell 8C-TAIXA1 51307127-175 conformal-coated 16-channel Series 8 analog input IOTA for 4–20 mA and HART applications.
HONEYWELL SERIES 8 ANALOG INPUT IOTA

8C-TAIXA1 · 16-Channel Analog Input Termination Assembly

A conformal-coated, non-redundant 6-inch IOTA for Series 8 high-level analog input with HART.

Product Overview

Honeywell 8C-TAIXA1 is the coated, non-redundant 6-inch input/output termination assembly (IOTA) used with the Series 8 8C-PAIHA1 high-level analog input module.

The IOTA provides the field termination and module interface for 16 single-ended current-input channels. Signal conversion and HART-capable input processing are performed by the compatible I/O module mounted on the assembly.

Specifications

Manufacturer Honeywell
Model 8C-TAIXA1
Existing page part reference 51307127-175
Assembly type Series 8 analog input IOTA
Coating Conformal coated
Redundancy Non-redundant
Form factor 6-inch IOTA
Compatible I/O module 8C-PAIHA1 high-level analog input with HART
Channels 16 single-ended
Input type Current; 2-wire and self-powered transmitters
Input range 4–20 mA through 250 Ω
A/D resolution 16 bit
Supply 24 VDC
Module current rating 110 mA
Scan period 50 ms
Maximum input ±30 V
Hardware accuracy ±0.075% FS at 23.5 ±2°C; ±0.15% FS from 0–60°C
Galvanic isolation 1000 VAC RMS or ±1000 VDC
Operating temperature 0–60°C
Storage temperature −40–85°C
Weight 0 kg entered because no official assembly weight was located

Features

  • Conformal-coated Series 8 IOTA construction.
  • Sixteen single-ended current-input terminations.
  • Supports the HART-capable 8C-PAIHA1 input module.
  • 50 ms input scan with 16-bit conversion in the compatible module.
  • Module insertion and removal under power is supported by the Series 8 design.
  • Galvanic isolation between field and system domains.

Applications

Designed for Honeywell Series 8 analog measurement loops using 4–20 mA field transmitters, including HART-enabled instruments when paired with the specified input module.

  • Process transmitter input termination
  • PlantCruise / Experion Series 8 I/O
  • Control-system maintenance and replacement

Lifecycle

Verify that the required item is the IOTA rather than the plug-in 8C-PAIHA1 I/O module. Also confirm coated hardware, non-redundant configuration, 6-inch form factor and the part number printed on the installed assembly before replacement.

FAQ

Is 8C-TAIXA1 the analog input processor?
It is the field termination assembly. The compatible 8C-PAIHA1 module performs input processing.
How many channels are supported?
Sixteen single-ended current-input channels.
Does it support HART?
Yes, when used with Honeywell's HART-capable 8C-PAIHA1 module.
Is it conformal coated?
Yes. The 8C prefix identifies the coated assembly in the official Series 8 selection table.
Why is the weight set to zero?
No manufacturer-published weight for the bare IOTA was located, so no third-party estimate is used.
