Honeywell TK-FPDXX2 TC-FPDXX2 Power Supply Module

Product Overview

Honeywell TK-FPDXX2 is the conformal-coated version of the Series A standard non-redundant DC power supply. It accepts a nominal 24 VDC plant supply and provides the regulated power rails required by modules installed in the associated chassis.

The unit is installed on the left side of the chassis and does not consume an I/O slot. Chassis loading and the operating environment must be checked before replacement or commissioning.

Specifications

Features

• Conformal-coated TK variant for environments requiring coated hardware.
• Wide 19.2–32 VDC input range for nominal 24 VDC systems.
• Supplies 1.2 V, 3.3 V, 5.1 V and 24 V backplane rails.
• Designed for side-of-chassis installation without using a module slot.
• Output loading limits are stated for operation up to 60°C.

Applications

Used in Honeywell Series A / Experion control chassis for maintenance, capacity planning and like-for-like replacement of the coated 24 VDC standard power-supply assembly.

• Process-control chassis power distribution
• Legacy Experion PKS system maintenance
• Coated-hardware replacement projects

Lifecycle

TK-FPDXX2 is legacy system hardware. Confirm the coated TK suffix, input voltage, chassis type, backplane load and connector arrangement against the installed system documentation before ordering. Do not substitute the uncoated TC-FPDXX2 where conformal coating is required.

FAQ
