ICS Triplex / Rockwell Automation T8431 40-Channel 24 V DC TMR Analog Input Module
A safety-system analog input module that applies triple modular redundancy and channel diagnostics across forty field inputs.
Technical Summary
The Trusted T8431 interfaces to 40 sourcing field devices and operates as the current sink for those inputs. Every channel is processed through an internal Triple Modular Redundant architecture.
Open- and short-circuit line monitoring can be selected independently by channel. The module also records Sequence of Events entries at 1 ms resolution when configured thresholds detect a state change.
For a controlled spare, retain the module series, chassis position, field termination arrangement, threshold configuration and Companion Slot or SmartSlot strategy as one system record.
Specifications
ICS Triplex / Rockwell Automation
T8431
24 V DC analog input
40 sourcing-device channels
TMR on every input channel
0–6 V DC / 0–22 mA
20–32 V DC
20 W
1 ms
2500 V impulse-withstand opto/galvanic barrier
Features
Channel-level fault tolerance
Three internal measurement paths support fault-tolerant acquisition without reducing the forty-point field count.
Selectable cable supervision
Each point can be configured to detect open- and short-circuit field wiring faults.
Online maintenance path
The manufacturer supports online replacement through an adjacent Companion Slot or a designated SmartSlot.
Visible operating state
Front indicators report channel condition, field-wiring faults, module health and Active, Standby or Educated status.
