Long controlled reach
The 12.0 in penetration establishes the sensor position in a deep mounting arrangement.
Bently Nevada 21000-16-10-00-120-03-02 Proximity Probe Housing Assemblies
Item NO.: 21000-16-10-00-120-03-02
Warranty: 1 year
Condition : brand new in factory sealed box
Email: sales@mvme.cn
Chat online: +86 18030175807
Detail
- Product NameBently Nevada 21000-16-10-00-120-03-02 Proximity Probe Housing Assemblies
- Item NO.21000-16-10-00-120-03-02
- Weight1.0000 kg = 2.2046 lb = 35.2740 oz
- CategoryTSI
- BrandBently Nevada
- Creation Time2025-03-21
21000 Proximity Probe HousingLong-Penetration Aluminum Probe Housing Assembly
3300 XL 8 MM PROBE · 1.0 M CABLE · 12.0 IN PENETRATION
Bently Nevada 21000-16-10-00-120-03-02 Aluminum 3300 XL 8 mm Probe Housing Assembly
A long-reach aluminum housing assembly with no standoff, a 1.0 m probe cable and the option 03 sealed conduit-entry package.
PRODUCT CONTEXT
Product Profile
21000-16-10-00-120-03-02 is a 21000 aluminum external-mount housing containing a 3300 XL 8 mm probe with a 1.0 m lead. The assembly has no standoff adapter and establishes a 12.0 in penetration.
Option 03 supplies the plug, reducer and cable-seal grip package, and the final 02 specifies a 3/4-14 NPT mounting thread. The complete geometry must be preserved for a long-reach installation.
CONTROLLED DATA
Technical Data
Manufacturer
Bently Nevada
Exact model
21000-16-10-00-120-03-02
Housing family
21000
Housing body
Aluminum
Sleeve material
304 stainless steel
Probe selection
3300 XL 8 mm
Probe cable
1.0 m (39 in)
Standoff adapter
None
Penetration length
12.0 in (304.8 mm)
Fitting package
Plug, reducer and cable-seal grip set
Mounting thread
3/4-14 NPT
OPERATING ROLE
System Role
01Long controlled reach02No-standoff geometry03Sealed cable-entry hardware04External adjustment access
No-standoff geometry
The housing is configured without a separate adapter.
Sealed cable-entry hardware
Option 03 carries the reducer and grip components required by the documented entry.
External adjustment access
The housing supports probe servicing from outside the machine case.
SELECTION BOUNDARY
Compatibility
21000-16-10-00-120-03-02
Measure the installed reach and available clearance before 21000-16-10-00-120-03-02 is removed or a spare is released.
21000 Proximity Probe Housing
Retain the installed host, project and connection evidence that defines the approved use of this execution.
Verified field fit
Complete the model-specific checks described in the service sequence before return to operation.
FIELD USE
Applications
Deep machine-case insertion
Locating a reverse-mount probe through a long controlled sleeve path.
Permanent 8 mm proximity monitoring
Serving a documented 3300 XL measurement chain.
Dimensional spare management
Maintaining the exact 12.0 in reach during overhaul planning.
MeasureRecord the 21000-16-10-00-120-03-02 label, 12.0 in insertion path, clearances and all chain identities.ExchangeSupport and align the long assembly while preserving the approved seal and thread procedure.ProveConfirm mechanical clearance, static gap, polarity and monitor response.
CUSTOMER QUESTIONS
FAQ
Q01
What installation evidence is most important for 21000-16-10-00-120-03-02?
Supply measured insertion, clearances, mounting photographs and complete probe-chain labels.
Q02
Can a shorter 21000 housing replace 21000-16-10-00-120-03-02?
No direct substitution should be assumed because the 12.0 in penetration determines sensor position.
Q03
Does 21000-16-10-00-120-03-02 use a standoff adapter?
No. The 00 field defines a no-standoff execution despite its long penetration.
Q04
Which cable-entry hardware belongs with 21000-16-10-00-120-03-02?
Option 03 identifies the plug, reducer and cable-seal grip package.
Q05
What proves 21000-16-10-00-120-03-02 is ready for service?
Correct reach and alignment plus a stable static gap and verified channel response complete acceptance.
