CC-TDOB11 is a digital output module from Honeywell's Series C I/O family, designed for the Experion PKS distributed control system. It provides 16 digital output channels with high-side switching capability, enabling reliable control of field devices such as solenoids, actuators, relays, and indicator lamps.

The module features 16 channels with individual output status indication, short-circuit protection, and overcurrent protection. It is designed for easy integration into the Series C I/O rack architecture, providing a robust and cost-effective solution for digital output applications.

CC-TDOB11 supports hot-swapping, allowing module replacement without system shutdown. Its conformal-coated PCB provides protection against moisture, dust, and corrosive atmospheres, making it suitable for harsh industrial environments.

• 16 digital output channels
• 24 VDC high-side switching
• Individual channel status LEDs
• Short-circuit protection
• Conformal-coated PCB

The CC-TDOB11 serves as the digital output interface between the Experion PKS control system and field devices. It receives digital command signals from the C300 controller and converts them into field-level switching outputs that directly drive solenoids, actuators, motor starters, relays, and other on/off field devices.

In typical installations, the module is installed in a Series C I/O rack and communicates with the C300 controller via the FTE (Fault Tolerant Ethernet) network. Each channel is individually isolated and protected, ensuring reliable operation even in the event of field wiring faults.

The module supports module-level and channel-level diagnostics, providing real-time feedback on output status, load conditions, and fault detection. This enables predictive maintenance and rapid fault identification, minimizing downtime in critical applications.

• Experion PKS Series C
• C300 controller connected
• FTE network communication
• Field device driving
• Redundant configurations
